High-pressure male BSP tapered push-in fittings M10x1.5-T4 Pneumatic push-in fittings

High-pressure male BSP tapered push-in fittings M10x1.5-T4

Product N° 0700 04 15
High-pressure male BSP tapered push-in fittings M10x1.5-T4 Pneumatic push-in fittings
Product in stock
Delivery 24/72h
My Wishlist Add to Wishlist

Helpful information:

➜ Scope of application: lubrication systems, transport, heavy industry (oil, water, grease, compressed air)

➜ Pressures:
- Minimum pressure: 0 bar (0 Mpa)
- Maximum working pressure (compressed air): 30 bar (3 Mpa)
- Maximum working pressure (with fluids): 150 bar (15 Mpa)

➜ Temperature:
- Minimum temperature: - 30°C
- Maximum temperature: + 150°C

➜ Thread: Tapered gas to ISO 7.1, BS 21, DIN 2999. Metric tapered to UNI 7707.

➜ Recommended tube: High-pressure PA6-6 nylon

➜ Standards: REACH 1907/2006, RoHS 2011/65/CE

➜ Materials: Nickel-plated brass, HNBR gasket
